# Server

Infrastructure-as-code and service definitions for luke-else.co.uk's self-hosted server estate: three [Hetzner Cloud](https://www.hetzner.com/cloud/) VPS instances provisioned with [OpenTofu](https://opentofu.org/), each bootstrapped and deployed with [Ansible](https://www.ansible.com/), running a set of Docker Compose stacks behind [Traefik](https://traefik.io/traefik/).

<p align="center">
  <img src="assets/images/main.png" width="70%">
</p>

## Contents

- [Architecture](#architecture)
- [Repository layout](#repository-layout)
- [Prerequisites](#prerequisites)
- [Provisioning the infrastructure](#provisioning-the-infrastructure-infra)
- [Bootstrapping and deploying with Ansible](#bootstrapping-and-deploying-with-ansible-ansible)
- [Service inventory](#service-inventory)
- [First-time setup](#first-time-setup)
- [Development container](#development-container)
- [Security notes](#security-notes)

## Architecture

Three servers, one shared private network:

```mermaid
architecture-beta
    group cloud(cloud)[Hetzner]

    group network(cloud)[network] in cloud

    service dev(mdi:server)[dev] in network

    service prod(mdi:server)[prod] in network
    service prodfirewall(mdi:firewall)[firewall] in cloud

    service vpn(mdi:server)[vpn] in cloud
    service vpnfirewall(mdi:firewall)[firewall] in cloud

    service gateway(mdi:web)[gateway] in cloud

    service backups(mdi:bucket)[S3 Backups]

    dev:L -- R:prod

    prod:B -- T:prodfirewall
    vpn:B -- T:vpnfirewall

    prodfirewall: L -- R: gateway
    vpnfirewall: B -- T: gateway

    dev:T -- B:backups
    prod:T -- B:backups
    vpn:R -- L:backups
```

`gateway` represents the public internet, not a provisioned resource. `backups` is the S3-compatible bucket every host's `backup-docker-compose.yml` pushes to and restores from - not a Hetzner resource, see [Persistent data lives in named Docker volumes, backed up to S3](#persistent-data-lives-in-named-docker-volumes-backed-up-to-s3).

| Server | Purpose | Network |
|---|---|---|
| `dev`  | Gitea, CI runner, dev-facing Traefik | Private network only (no public firewall exposure beyond CI/CD) |
| `prod` | Public-facing websites, Bitwarden, RustDesk, status page, prod Traefik | Private network + public firewall |
| `vpn`  | OpenVPN + its own Traefik | **Not** attached to the private network — kept isolated so a compromised VPN endpoint can't pivot to `dev`/`prod` |

Each host's stateful data lives in local named Docker volumes, backed up nightly to a shared S3 bucket and restored automatically on first boot - see below. No host has a Hetzner Cloud Volume attached any more.

`dev` and `prod` share a private Hetzner network (`10.0.1.0/24` by default) so CI/CD on `dev` can reach deployment targets on `prod` without exposing that traffic publicly. `vpn` is deliberately kept off this network. Each server has its own Hetzner Cloud Firewall (see `infra/modules/<host>/main.tf`) that only opens the ports actually used by the compose stacks running on it, plus SSH restricted to `var.allowed_ssh_source_ips`.

## Repository layout

```
.
├── infra/                    # OpenTofu (Terraform-compatible) config — provisions the 3 servers, network, firewalls, DNS
│   ├── main.tf                # root module: wires network + dev/prod/vpn/dns modules together
│   ├── variables.tf           # shared inputs (sizes, locations, IP ranges, SSH key names)
│   ├── outputs.tf             # pass-through outputs from each host module
│   ├── ssh.tf                 # looks up each SSH key already uploaded to Hetzner Cloud
│   ├── versions.tf            # provider requirements
│   ├── terraform.tfvars.example
│   └── modules/
│       ├── network/           # shared private network + subnet (used by dev and prod)
│       ├── dev/                # dev server + firewall, labeled role=dev
│       ├── prod/               # prod server + firewall, labeled role=prod
│       ├── vpn/                # vpn server + firewall (no private network), labeled role=vpn
│       └── dns/                # Hetzner DNS zones + A records for every domain in var.dns_zones
├── ansible/                   # Ansible: bootstraps each server and deploys/starts services/<host>/ onto it
│   ├── inventory/hcloud.yml   # dynamic inventory — queries the Hetzner API, groups by the role label above
│   ├── group_vars/            # deploy_user, dev_runner_count, backup_s3_*, etc.
│   ├── roles/
│   │   ├── bootstrap/          # Docker, deploy user, sshd hardening, unattended-upgrades
│   │   └── deploy/             # copies services/<host>/, renders .env (S3 backup credentials) + Runners/docker-compose.yml
│   └── playbooks/              # bootstrap.yml, deploy.yml, spinup.yml, spindown.yml, site.yml
├── services/                 # Docker Compose stacks, grouped by which server they run on
│   ├── dev/                   # Gitea + CI runner + Traefik + backup/restore (git.luke-else.co.uk, cicd.luke-else.co.uk)
│   ├── prod/                  # Websites, Bitwarden, RustDesk, status page + Traefik + backup/restore
│   ├── vpn/                    # OpenVPN + Traefik + backup/restore
│   └── todo.md                # Outstanding manual setup/hardening tasks
├── docs/
│   └── architecture.md       # Source of the architecture diagram above
├── .devcontainer/             # Git submodule: shared devcontainer for working on this repo (OpenTofu tooling)
└── assets/
```

Each of `services/dev`, `services/prod`, `services/vpn` follows the same convention: one `*-docker-compose.yml` (or subdirectory, e.g. `Runners/`) per logical service, a `backup-docker-compose.yml` + `restore.sh` pair for that host's S3 backup/restore (see below), plus a `spinup.sh` / `spindown.sh` pair that brings up or tears down every stack on that host in the right order. `infra/modules/` and `ansible/roles/deploy` both mirror this same dev/prod/vpn split, so a given host's cloud resources, bootstrap/deploy logic, and compose stacks are easy to find side by side.

OpenTofu and Ansible have a clean split: OpenTofu only ever provisions cloud resources (servers, network, firewalls, DNS) and never touches anything over SSH. Everything from "the server exists" onward — installing Docker, creating the `deploy` user, hardening SSH, copying `services/<host>/`, and running `spinup.sh`/`spindown.sh` — is Ansible's job. See [`ansible/README.md`](ansible/README.md) for the full rundown.

## Prerequisites

- A [Hetzner Cloud](https://console.hetzner.cloud/) project and API token
- One or more SSH keys uploaded to that project (Console → Security → SSH Keys) - all are installed on every server - plus the private key matching one of them available locally (Ansible uses it to bootstrap and deploy — see below)
- [OpenTofu](https://opentofu.org/docs/intro/install/) `>= 1.6.0`
- [Ansible](https://docs.ansible.com/ansible/latest/installation_guide/index.html) `>= 2.15` and the `hetzner.hcloud` collection (`ansible-galaxy collection install -r ansible/requirements.yml`)
- Ownership of the domains in `var.dns_zones` at whatever registrar they're bought through, so you can point their NS records at Hetzner (see [Managing DNS](#managing-dns) — the zones and records themselves are created for you)
- An S3-compatible bucket (e.g. [Hetzner Object Storage](https://www.hetzner.com/storage/object-storage/), AWS S3, or any other S3-compatible provider) and an access key/secret pair with read/write access to it - not provisioned by OpenTofu (the `hcloud` provider has no Object Storage resource), so create this yourself and pass it to Ansible as `BACKUP_S3_BUCKET`/`BACKUP_S3_ACCESS_KEY_ID`/`BACKUP_S3_SECRET_ACCESS_KEY` (and `BACKUP_S3_ENDPOINT` for anything other than real AWS S3) - see [Persistent data lives in named Docker volumes, backed up to S3](#persistent-data-lives-in-named-docker-volumes-backed-up-to-s3)

Docker + the Compose plugin, the non-root `deploy` user, and SSH hardening no longer need doing by hand — Ansible's `bootstrap` role handles all of that (see below).

## Provisioning the infrastructure (`infra/`)

```sh
cd infra
export HCLOUD_TOKEN=your-hetzner-api-token   # never commit this
cp terraform.tfvars.example terraform.tfvars
$EDITOR terraform.tfvars                     # set ssh_key_names at minimum

tofu init
tofu plan
tofu apply
```

This creates, via `module.network` / `module.dev` / `module.prod` / `module.vpn` / `module.dns` in `infra/main.tf`:
- `hcloud_network` + subnet, shared by `dev` and `prod` (`modules/network`)
- one `hcloud_server` + `hcloud_firewall` per host, scoped to the ports each host actually uses, each server labeled `role = "dev"/"prod"/"vpn"` for Ansible's dynamic inventory (`modules/dev`, `modules/prod`, `modules/vpn`)
- one Hetzner DNS zone per domain in `var.dns_zones`, plus every A record in [Service inventory](#service-inventory) (`modules/dns` — see [Managing DNS](#managing-dns))

No servers have an attached volume — persistent data lives in named Docker volumes backed up to S3 instead, see below.

Useful outputs: `tofu output dev_ipv4`, `tofu output prod_ipv4`, `tofu output vpn_ipv4`, `tofu output dns_nameservers`.

`terraform.tfvars` and any `*.tfvars` file are gitignored — never commit real values there. Defaults for server sizes, locations, and IP ranges live in `infra/variables.tf` and are passed down into the modules from `infra/main.tf`; override them per-environment via `terraform.tfvars`.

OpenTofu never connects to the servers over SSH — no provisioners, no `bootstrap.sh`, no copying `services/` — that's all Ansible now. See below.

### Managing DNS

`module.dns` (in `infra/modules/dns`) creates one Hetzner DNS zone per domain in `var.dns_zones` (default: `luke-else.co.uk`, `divine-couture.co.uk`, `snexo.co.uk`) and an `hcloud_zone_rrset` A record for every hostname currently referenced by a Traefik `Host()` rule anywhere under `services/` — kept in sync with `local.dns_records` in `infra/main.tf`, pointed at whichever of `dev`/`prod`/`vpn` actually serves it. Zones have `prevent_destroy = true`, matching the volumes — losing one deletes every record in it.

Creating the zone doesn't make Hetzner authoritative for the domain by itself: you still need to point that domain's NS records at Hetzner's nameservers at whichever registrar it's registered through. Run `tofu output dns_nameservers` after applying to get the exact nameservers per domain, and set those as the domain's NS records at the registrar. Propagation can take a while depending on the registrar and the domain's previous NS TTL.

Adding a new subdomain: add an entry to `local.dns_records` in `infra/main.tf` (zone, name, and the target `module.<host>.ipv4`) and re-run `tofu apply` — don't hand-create records in the Hetzner console, they'll drift from state. Note `name = "@"` is Hetzner's convention for a zone's apex record (e.g. bare `snexo.co.uk`), not an empty string.

Only A records for IPv4 are managed here — none of the modules currently track servers' IPv6 addresses, so AAAA records aren't generated even though the firewalls already allow IPv6 traffic.

## Bootstrapping and deploying with Ansible (`ansible/`)

Once `tofu apply` has created the servers, [`ansible/`](ansible/README.md) takes over everything else: installing Docker, creating the `deploy` user, hardening SSH, copying `services/<host>/` to each server, rendering `.env` (S3 backup credentials) and, for `dev`, `Runners/docker-compose.yml`, and running `spinup.sh`/`spindown.sh`. Full detail lives in [`ansible/README.md`](ansible/README.md); the short version:

```sh
cd ansible
ansible-galaxy collection install -r requirements.yml
export HCLOUD_TOKEN=your-hetzner-api-token   # never commit this

# vpn first - its firewall accepts SSH from var.allowed_ssh_source_ips directly
ansible-playbook playbooks/site.yml -l role_vpn

# SSH to vpn as deploy and connect to the OpenVPN it just started, then:
ansible-playbook playbooks/site.yml -l role_dev,role_prod
```

Hosts are discovered dynamically from the Hetzner API (`ansible/inventory/hcloud.yml`), grouped into `role_dev`/`role_prod`/`role_vpn` by the `role` label OpenTofu sets on each server — there's no static inventory file to keep in sync, and nothing here reads Terraform state.

### Persistent data lives in named Docker volumes, backed up to S3

Every stateful service's compose file mounts a plain named Docker volume rather than a bind mount to a Hetzner volume - `gitea_data:/data`, `bitwarden_data:/data/`, `letsencrypt_data:/letsencrypt`, and so on across `services/dev/*.yml`, `services/prod/*.yml`, and `services/vpn/*.yml`. Each volume is declared with an explicit `name:` in every compose file that mounts it (the same pattern already used for the shared `proxy` network), so Compose creates it once and every stack that references it reuses the same underlying volume regardless of which compose file happens to run first.

Each host's `backup-docker-compose.yml` defines two services against those same named volumes:
- **`backup`** — [`offen/docker-volume-backup`](https://github.com/offen/docker-volume-backup), running on a nightly cron (`0 3 * * *`), tars up every mounted volume and uploads it to `s3://$AWS_S3_BUCKET_NAME/$AWS_S3_PATH/<host>-<timestamp>.tar.gz`, keeping 14 days of history (`BACKUP_RETENTION_DAYS`). Containers labeled `docker-volume-backup.stop-during-backup=true` (Gitea, Bitwarden, RustDesk, Uptime Kuma, snexo, OpenVPN) are stopped for the duration of the backup so their data is captured in a consistent state, then restarted automatically. Started by `spinup.sh` alongside everything else.
- **`restore`** — a one-shot container (`amazon/aws-cli` running `restore.sh`) that `spinup.sh` runs *before* anything else starts. It checks each of the host's named volumes; any that are already empty are populated from the most recent object under that host's S3 prefix, any that already contain data are left completely untouched. On a fresh server with no prior backup (or a bucket that doesn't exist yet), it's a no-op - services just start with empty volumes as before.

`AWS_S3_BUCKET_NAME`, `AWS_S3_PATH` (set to the host name, e.g. `dev`), `AWS_ACCESS_KEY_ID`, `AWS_SECRET_ACCESS_KEY`, and `AWS_ENDPOINT` are rendered into `services/<host>/.env` by Ansible's `deploy` role from `BACKUP_S3_BUCKET`/`BACKUP_S3_ACCESS_KEY_ID`/`BACKUP_S3_SECRET_ACCESS_KEY`/`BACKUP_S3_ENDPOINT` in your shell environment (see [Prerequisites](#prerequisites)) — `docker compose` auto-loads `.env` from its working directory. `spinup.sh` on every host refuses to start anything if `.env` is missing.

The Gitea Actions runners are the one exception: their `/data` is a disposable local cache (runner identity re-registers with Gitea on every `spinup.sh` run anyway), so it's a plain named volume per runner (`gitea_runner_N_data`, baked directly into the rendered `Runners/docker-compose.yml`) that's deliberately left out of the backup/restore stack.

To trigger a backup or restore manually rather than waiting for cron or a restart:

```sh
cd services/<host>
docker compose -f backup-docker-compose.yml exec backup backup   # force an immediate backup
docker compose -f backup-docker-compose.yml run --rm restore     # restore any currently-empty volumes
```

### Scaling Gitea Actions runners

The number of Gitea Actions runner containers on `dev` is set by `dev_runner_count` in [`ansible/group_vars/role_dev.yml`](ansible/group_vars/role_dev.yml) (default `3`). Re-running `ansible-playbook playbooks/deploy.yml -l role_dev` renders [`roles/deploy/templates/runners-docker-compose.yml.j2`](ansible/roles/deploy/templates/runners-docker-compose.yml.j2) straight onto the server as `services/dev/Runners/docker-compose.yml` — one `runner-N` service per count, each with its own container name and `/data` volume so their registrations don't collide. That file is generated on the remote host: change `dev_runner_count` and redeploy rather than hand-editing it.

Rendering it doesn't start anything by itself — re-run `ansible-playbook playbooks/spinup.yml -l role_dev` afterwards to apply a count change.

Registration tokens are handled automatically, not baked into the generated file: `services/dev/spinup.sh` waits for Gitea to come up, runs `gitea actions generate-runner-token` inside the Gitea container, and writes the result to `Runners/.env`, which Compose loads automatically. There's no manual admin-UI step for this anymore.

### First deploy: bootstrapping order matters

`dev` and `prod`'s firewalls only accept SSH from `vpn`'s public IP (see [Security notes](#security-notes)), but `vpn`'s own OpenVPN service isn't running until you deploy it — so on a from-scratch estate, Ansible can't reach `dev`/`prod` yet. Bring it up in this order:

1. `ansible-playbook playbooks/site.yml -l role_vpn` — bootstraps, deploys, and starts `vpn` only; its firewall allows SSH from `var.allowed_ssh_source_ips` directly.
2. SSH in as `deploy` and connect to the OpenVPN service you just started with an OpenVPN client.
3. `ansible-playbook playbooks/site.yml -l role_dev,role_prod` — now that your machine is tunneled through `vpn`, its NATed egress IP matches the firewall rule and `dev`/`prod` become reachable.

If step 3 is run before you're connected to the VPN, Ansible will simply fail to connect — re-run it once connected.

## Deploying the services (`services/`)

After `ansible-playbook playbooks/deploy.yml` has copied `services/<host>/` to `/home/deploy/services/<host>` on the matching server, SSH in as `deploy` and run the matching script from inside that directory — or just use `ansible-playbook playbooks/spinup.yml` / `spindown.yml`, which do exactly this remotely (see [`ansible/README.md`](ansible/README.md)):

```sh
# on dev
./spinup.sh     # Traefik → Gitea → (waits, generates a runner token) → Runners → Watchtower
./spindown.sh   # reverse order, then prunes images/volumes

# on prod
./spinup.sh    # Traefik, → Watchtower → status → websites → Bitwarden → RustDesk
./spindown.sh

# on vpn
./spinup.sh     # Traefik → OpenVPN → Watchtower
./spindown.sh
```

If you ever need to force a re-sync without going through Ansible (e.g. testing a local edit before committing it), a manual `scp -r services/prod deploy@<prod_ipv4>:~/services` still works fine - `ansible-playbook playbooks/deploy.yml` will just overwrite it again next time it's run.

Each stack can also be managed individually with plain Compose, e.g.:

```sh
cd services/prod
docker compose -f bitwarden-docker-compose.yml up -d
docker compose -f bitwarden-docker-compose.yml down
```

All three hosts run [Watchtower](https://containrrr.dev/watchtower/) polling every 60s with cleanup enabled, so images are kept current automatically once deployed — the spinup scripts only need to be re-run after adding/removing a service or changing compose files.

Every public-facing service is fronted by its host's own Traefik instance, terminating TLS via Let's Encrypt (`tlschallenge`, port 80/443). Each stack joins an external `proxy` Docker network and opts in via `traefik.enable=true` labels rather than publishing ports directly (RustDesk and the Gitea SSH port are the deliberate exceptions, since they aren't HTTP).

## Service inventory

### `dev`

| Service | Compose file | Domain(s) |
|---|---|---|
| Traefik | `traefik-docker-compose.yml` | `traefik.cicd.luke-else.co.uk` |
| Gitea | `gitea-docker-compose.yml` | `git.luke-else.co.uk` (HTTP), SSH on `222` |
| Gitea Actions runner(s) | `Runners/docker-compose.yml` (generated — see [Scaling Gitea Actions runners](#scaling-gitea-actions-runners)) | N/A |
| Watchtower | `watchtower-docker-compose.yml` | — |
| Backup/restore | `backup-docker-compose.yml` | — |

### `prod`

| Service | Compose file | Domain(s) |
|---|---|---|
| Traefik | `traefik-docker-compose.yml` | `traefik.luke-else.co.uk` |
| Websites | `web-docker-compose.yml` | `luke-else.co.uk`, `dev.luke-else.co.uk`, `metarius.luke-else.co.uk`, `www.divine-couture.co.uk`, `snexo.co.uk` |
| Status page (Uptime Kuma) | `status-docker-compose.yml` | `status.luke-else.co.uk` |
| Bitwarden (Vaultwarden) | `bitwarden-docker-compose.yml` | `bitwarden.luke-else.co.uk` |
| RustDesk relay (hbbs/hbbr) | `rd-docker-compose.yml` | `rd.luke-else.co.uk`, ports `21115-21119` |
| Watchtower | `watchtower-docker-compose.yml` | — |
| Backup/restore | `backup-docker-compose.yml` | — |

### `vpn`

| Service | Compose file | Domain(s) |
|---|---|---|
| Traefik | `traefik-docker-compose.yml` | `traefik.vpn.luke-else.co.uk` |
| OpenVPN (Dockovpn) | `vpn-docker-compose.yml` | `vpn.luke-else.co.uk`, UDP `1194` |
| Watchtower | `watchtower-docker-compose.yml` | — |
| Backup/restore | `backup-docker-compose.yml` | — |

## First-time setup

A few things need manual attention before a stack is fully live — tracked in [`services/todo.md`](services/todo.md), summarized here:

- **General host hardening**: non-root user, Docker, and unattended-upgrades are now handled automatically by [Ansible's `bootstrap` role](ansible/roles/bootstrap/tasks/main.yml); UFW is the remaining manual item in `services/todo.md` (the Hetzner Cloud Firewalls already allowlist per-host ports — see [Security notes](#security-notes)).

## Development container

`.devcontainer` is a git submodule providing a ready-to-use OpenTofu development environment (VS Code + OpenTofu/Docker/Mermaid extensions). After cloning:

```sh
git submodule update --init --recursive
```

Then reopen the repo in VS Code with the Dev Containers extension.

## Security notes

- Real secrets (`HCLOUD_TOKEN`, `BACKUP_S3_ACCESS_KEY_ID`/`BACKUP_S3_SECRET_ACCESS_KEY`, `*.tfvars`, your SSH private key) must never be committed — see `.gitignore`. The S3 credentials end up in each host's `services/<host>/.env` (rendered by Ansible, mode `0600`, gitignored) - anyone with root on a host can read them, same trust boundary as everything else `deploy` can already do there.
- SSH to `dev` and `prod` is restricted to the `vpn` server's own public IP — you must be tunneled into the VPN to reach them over SSH. SSH to `vpn` itself is gated by `var.allowed_ssh_source_ips`; narrow this from the default `0.0.0.0/0` once you know your own egress IP(s).
- `vpn` is intentionally excluded from the private network so that a compromised VPN endpoint cannot reach `dev` or `prod` directly over it — SSH access still works because the VPN's egress traffic is NATed through its own public IP.
- Firewalls are allowlists scoped per host in `infra/modules/<host>/main.tf` — only ports actually used by that host's compose stacks (plus the cross-host private network range) are open.
- Every host's [Ansible bootstrap role](ansible/roles/bootstrap/tasks/main.yml) disables SSH password authentication, restricts root login to key-only, and creates a separate sudo user (`deploy_user`, see `ansible/group_vars/all.yml`) for day-to-day access.
- DNS zones (`modules/dns`) carry both Hetzner's own `delete_protection` and Terraform's `prevent_destroy` — losing a zone takes every record in it with it, including for `divine-couture.co.uk` and `snexo.co.uk`, not just `luke-else.co.uk`.
